Product Description
20x2 character LCD display module factory
| Outsize | 116x37x13.2mm |
| LCD type | STN,TRANSFLECTIVE/Positive |
| View Area | 83x18.6mm |
| Drive Method | 1/16duty,1/5bias |
| Connector | PIN |
| View angle | 6:00 |
| Voltage | 5.0V |
| Operating temperature | -20-70c |
| Storage temperature | -30-80c |
| Driver | SPLC780D |
LCD Drawing
PIN Assignment Or Interface of Connecter
LCD Color Supplied For Your Choice
Potential Applications
1. Portable test equipment
2.Measuring Device
3.Diagnostics device
4.Automotive display
5.Medical equipment
6.Electric ,water, gas meters, energy meter
7.Marine equipment
8.Telecom products
Application On Product Picture
