Custom STN LCD 24x2 Graphic Display Module
Product Description
Custom STN LCD 24x2 Graphic Display Module
| LCD Type | STN - Super-Twisted Nematic |
| Display Mode | Transflective |
| Number of Characters | 48 |
| Display Format | 24x 2 |
| Character Format | 5 x 8 Dots |
| Character Size | 5.55mm H x 2.70mm W |
| Outline Dimension | 116.00mm x 37.00mm x 13.50mm |
| Viewing Area | 83.00mm L x 18.60mm W |
| Backlight | LED - White |
| Voltage -Supply | 4.7 V ~ 5.5 V |
| Operating Temperature | -20°C ~ 70°C |
| Dots size | 0.50mm W x 0.65mm H |
| Interface | -Parallel |
| Text color | Blue |
| Background color | White |
